如何用AI生成精美的光固化3D打印机零件爆炸图

提示词

Technical exploded-view diagram of a resin 3D printer (LCD/MSLA type), isometric cutaway perspective, professional engineering illustration on neutral light gray background. Vertical explosion from bottom to top: base housing with ventilation, UV LED light source array (405nm), Fresnel collimating lens, 4K monochrome LCD screen with pixel matrix detail, FEP film in aluminum vat frame, anodized aluminum resin tank. Upper section: ball screw Z-axis with dual linear rails, stepper motor with gearbox, CNC-machined aluminum build platform with textured surface, quick-release mechanism. Enclosure: orange UV-blocking acrylic cover, activated carbon air filter, capacitive touchscreen. Electronics: control board, LED driver, power supply. Inset detail: UV rays through LCD, liquid resin layer, cured layer on platform. All component labels in Chinese, clean numbered callouts with Chinese technical terminology

声明： 图文中涉及的机器机构及零件标注名称与位置仅供示意参考，不一定完全准确，请以专业技术资料为准。
